PIC16C622A-04I/P - MICROCHIP TECHNOLOGY - EPROM-BASED 8-BIT CMOS MICROCONTROLLER
High Light: |
micro controller unit,microchip microcontroller |
---|
Quick Detail:
EPROM-Based 8-Bit CMOS Microcontroller
Description:
• Only 35 instructions to learn
• All single-cycle instructions (200 ns), except for program branches which are two-cycle
• Operating speed:
- DC - 20 MHz clock input
- DC - 200 ns instruction cycle
• Interrupt capability
• 16 special function hardware registers
• 8-level deep hardware stack
• Direct, Indirect and Relative addressing modes
Applications:
• 13 I/O pins with individual direction control
• High current sink/source for direct LED drive
• Analog comparator module with:
- Two analog comparators
- Programmable on-chip voltage reference (VREF) module
- Programmable input multiplexing from device inputs and internal voltage reference
- Comparator outputs can be output signals
• Timer0: 8-bit timer/counter with 8-bit programmable prescaler
Special Microcontroller Features:
• Power-on Reset (POR)
• Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
• Brown-out Reset
• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
Special Microcontroller Features (cont’d)
• Programmable code protection
• Power saving SLEEP mode
• Selectable oscillator options
• Serial in-circuit programming (via two pins)
• Four user programmable ID locations
Specifications:
Datasheets | PIC16C62x PIC16C62x Rev. A Silicon, Data Sheet Errata Tips N Tricks Guide MPLAB® ICE2000 Spec |
Product Photos | 18-DIP (300mil)_SDIP18 Pkg |
Product Training Modules | Asynchronous Stimulus 8-bit PIC® Microcontroller Portfolio |
Standard Package | 25 |
Category | Integrated Circuits (ICs) |
Family | Embedded - Microcontrollers |
Series | PIC® 16C |
Packaging | Tube |
Core Processor | PIC |
Core Size | 8-Bit |
Speed | 4MHz |
Connectivity | - |
Peripherals | Brown-out Detect/Reset, POR, WDT |
Number of I /O | 13 |
Program Memory Size | 3.5KB (2K x 14) |
Program Memory Type | OTP |
EEPROM Size | - |
RAM Size | 128 x 8 |
Voltage - Supply (Vcc/Vdd) | 2.5 V ~ 5.5 V |
Data Converters | - |
Oscillator Type | External |
Operating Temperature | -40°C ~ 85°C |
Package / Case | 18-DIP (0.300", 7.62mm) |
Catalog Page | 608 (CN081 PDF) |
For Use With | ISPICR1-ND - ADAPTER IN-CIRCUIT PROGRAMMING AC164010-ND - MODULE SKT PROMATEII DIP/SOIC |
