JFET Low Power LED Driver IC 4.0 MHz Wide Bandwidth High Slew Rate

Minimum Order Quantity: 1
JFET Low Power LED Driver IC 4.0 MHz Wide Bandwidth High Slew Rate
Features Gallery Product Description Request A Quote
Manufacturer Part Number: MC34182D
Brand Name: Original
Type: Electronic Component
Place Of Origin: Original
Inductor: LED
IGBT Module: High-frequency Tube
High Light:



LED Driver IC 4.0 MHz


Low Power LED Driver 4.0 MHz

Basic Infomation
Place of Origin: Original Factory
Brand Name: ON Semiconductor
Certification: Lead free / RoHS Compliant
Model Number: MC34182D
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 1000
Product Description

MC34182D - ON Semiconductor - Low Power, High Slew Rate, Wide Bandwidth, JFET Input Operational Amplifiers


Detailed Product Description
High Light:

power led driver circuit


led matrix driver ic




Quick Detail:


Low Power, High Slew Rate, Wide Bandwidth, JFET Input Operational Amplifiers





Quality bipolar fabrication with innovative design concepts are employed for the MC33181/2/4, MC34181/2/4 series of monolithic operational amplifiers. This JFET input series of operational amplifiers operates at 210 µA per amplifier and offers 4.0 MHz of gain bandwidth product and 10 V/µs slew rate. Precision matching and an innovative trim technique of the single and dual versions provide low input offset voltages. With a JFET input stage, this series exhibits high input resistance, low input offset voltage and high gain. The all NPN output stage, characterized by no deadband crossover distortion and large output voltage swing, provides high capacitance drive capability, excellent phase and gain margins, low open loop high frequency output impedance and symmetrical source/sink AC frequency response.

The MC33181/2/4, MC34181/2/4 series of devices are specified over the commercial or industrial/vehicular temperature ranges. The complete series of single, dual and quad operational amplifiers are available in the plastic DIP as well as the SOIC surface mount packages.





• Low Supply Current: 210 µA (Per Amplifier)

• Wide Supply Operating Range: ±1.5 V to ±18 V

• Wide Bandwidth: 4.0 MHz

• High Slew Rate: 10 V/µs

• Low Input Offset Voltage: 2.0 mV

• Large Output Voltage Swing: –14 V to +14 V (with ±15 V Supplies)

• Large Capacitance Drive Capability: 0 pF to 500 pF

• Low Total Harmonic Distortion: 0.04%

• Excellent Phase Margin: 67°

• Excellent Gain Margin: 6.7 dB

• Output Short Circuit Protection

• Offered in New TSSOP Package Including the Standard SOIC and DIP Packages





part no. MC34182D
Manufacturer ON Semiconductor
supply ability 10000
datecode 10+
package SMD

new and original stock
