Manufacturer Part Number: TLC5916IPW
Brand Name: Original Brand
Type: Integrated Circuit
Place Of Origin: Original Manufacturer
Quality: 100% Original 100% Brand
Lead Time: 1-7Working
High Light:

277v LED Display Driver IC


AC100 LED Display Driver IC



Basic Infomation
Place of Origin: Original Factory
Brand Name: Texas Instruments
Model Number: TLC5916IPW
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 1000
Product Description



Light Source: LED Input Voltage(v): AC100-277V
Working Lifetime(hour): 50000 Led Light Source: SMD
Product Name: Outdoor Led Street Light
High Light:

277V Display Driver IC


120mA Display Driver IC





Display Driver IC Texas Instruments/TI TLC5916IPW

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Limited
Fake Threat In the Open Market 37 pct.
Popularity High
Is this a common-used part? Yes
Case / Package 16-TSSOP
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 125°C (TA)
Applications Signage
Frequency 30MHz
Operating Input Voltage(Min) 3V
Number of Outputs 8
Internal Switch(s) Yes
Topology Shift Register
Maximum Supply Voltage 5.5V
Status Active
Packaging Reel - TR
Manufacturer Texas Instruments
Categories Integrated Circuits
Output Voltage 20V
Channel Output Current 120mA
Type Linear


Features for the TLC5916

  • Eight Constant-Current Output Channels
  • Output Current Adjusted Through Single External Resistor
  • Constant Output Current Range: 3-mA to 120-mA per Channel
  • Constant Output Current Invariant to Load Voltage Change
  • Open Load, Short Load and Overtemperature Detection
  • 256-Step Programmable Global Current Gain
  • Excellent Output Current Accuracy:
    • Between Channels: < ±3% (Maximum)
    • Between ICs: < ±6% (Maximum)
  • Fast Response of Output Current
  • 30-MHz Clock Frequency
  • Schmitt-Trigger Input
  • 3.3-V or 5-V Supply Voltage
  • Maximum LED Voltage 20-V
  • Thermal Shutdown for Overtemperature Protection
    • General LED Lighting Applications
    • LED Display Systems
    • LED Signage
    • Automotive LED Lighting
    • White Goods
    • Gaming Machines/Entertainment

All other trademarks are the property of their respective owners

Description for the TLC5916

The TLC591x Constant-Current LED Sink Drivers are designed to work alone or cascaded. Since each output is independently controlled, they can be programmed to be on or off by the user. The high LED voltage (VLED) allows for the use of a single LED per output or multiple LEDs on a single string. With independently controlled outputs supplied with constant current, the LEDs can be combined in parallel to create higher currents on a single string. The constant sink current for all channels is set through a single external resistor. This allows different LED drivers in the same application to sink various currents which provides optional implementation of multi-color LEDs. An additional advantage of the independent outputs is the ability to leave unused channels floating. The flexibility of the TLC591x LED drivers is ideal for applications such as (but not limited to): 7-segment displays, scrolling single color displays, gaming machines, white goods, video billboards and video panels.
