J1026F21CNL - PULSE A TECHNITROL COMPANY PULSEJACKTM 1X1 TAB-UP RJ45
| Catalog Drawings: | PULSEJACK Right Angle 1x1 | Category: | Connectors, Interconnects |
|---|---|---|---|
| Orientation: | 90° Angle (Right) | Contact Finish Thickness: | 15µin (0.38µm) |
| High Light: | power led driver circuit,offline led driver ic | ||
Quick Detail:
PULSEJACKTM 1x1 Tab-UP RJ45
Description:
10/100 Base-TX RJ45 1x1 Tab-UP with LEDs 8-pin (J1 series) and 6-pin (JP series) integrated magnetics connector, designed to support applications, such as ADSL modems, LAN-on-Motherboard, and Hub and Switches.
Applications:
RoHS-5 peak wave solder temperature rating 235°C
RoHS-6 peak wave solder temperature rating 260°C
Suitable for CAT 5 & 6 Fast Ethernet Cable or better UTP
Specifications:
| Datasheets | J1,JP Series |
| Product Photos | J1026F21C(NL) |
| Catalog Drawings | PULSEJACK Right Angle 1x1 |
| Standard Package | 25 |
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Series | PULSEJACK™ J1 |
| Packaging | Bulk |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-TX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.550" (13.97mm) |
| LED Color | Yellow - Green |
| Number of Cores per Jack | 5 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Up |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 15µin (0.38µm) |
| Shield Material | Brass |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
| Catalog Page | 309 (CN081 PDF) |
| Other Names | 553-1352 |
