EMI Power Management Chips ICs TPSM560R6RDAR For Controller / Driver

Minimum Order Quantity: 5 PCS
EMI Power Management Chips ICs TPSM560R6RDAR For Controller / Driver
Features Gallery Product Description Request A Quote
Manufacturer Part Number: TPSM560R6RDAR
Brand Name: Original
Type: Integrated Circuit
DC: Lastest New
Port: Shenzhen Or Hongkong
Lead Time: 1-3Working Days
High Light:

EMI Power Management Chips


Power Management Chips ICs


EMI Power Management ICs

Basic Infomation
Place of Origin: Original Factory
Brand Name: Texas Instruments
Certification: Standard Certification
Model Number: TPSM560R6RDAR
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 1000
Product Description



Type: Drive IC Shipping Way: Post Office And So On
Shipping Ways: DHL FEDEX UPS EMS TNT Application: Driver/Controller
Whatsapp: 86-15007558828
High Light:

Controller Power Management ICs


EMI Power Management ICs





Power Management ICs Texas Instruments/TI TPSM560R6RDAR

Iout (Max) (A) 0.6
Vin (Min) (V) 4.2
Vin (Max) (V) 60
Vout (Min) (V) 1
Vout (Max) (V) 6
Soft start Fixed
Features EMI Tested, Enable, Overcurrent protection, Power Good
Operating temperature range (C) -40 to 125
Iq (Typ) (uA) 26
Regulated outputs (#) 1
Switching frequency (Max) (kHz) 460
Switching frequency (Min) (kHz) 340
Duty cycle (Max) (%) 91
Topology Buck, Inverting Buck-Boost, Synchronous Buck


Features for the TPSM560R6

  • 5.0-mm × 5.5-mm × 4.0-mm Enhanced HotRod™ QFN
    • Excellent thermal performance: up to 18-W output power at 85°C, no airflow
    • Standard footprint: single large thermal pad and all pins accessible from perimeter
  • Designed for reliable and rugged applications
    • Wide input voltage range: 4.2 V to 60 V
    • Input voltage transient protection up to 66 V
    • Operating junction range: –40°C to +125°C
    • EXT-suffix junction range: –55°C to +125°C
  • Fixed 400-kHz switching frequency
  • FPWM mode of operation
  • Optimized for ultra-low EMI requirements
    • Integrated shielded inductor and high-frequency bypass capacitors
    • Meets EN55011 EMI standards
    • Spread spectrum option reduces emissions
  • 26-µA nonswitching quiescent current
  • Monotonic start-up into prebiased output
  • No loop-compensation or bootstrap components
  • Precision enable and input UVLO with hysteresis
  • Thermal shutdown protection with hysteresis

Description for the TPSM560R6

The TPSM560R6 power module is a highly integrated 600-mA power solution that combines a 60-V input, step-down DC/DC converter with power MOSFETs, a shielded inductor, and passives in a thermally-enhanced QFN package. The 5.0-mm × 5.5-mm × 4.0-mm, 15-pin QFN package uses Enhanced HotRod QFN technology for enhanced thermal performance, small footprint, and low EMI. The package footprint has all pins accessible from the perimeter and a single large thermal pad for simple layout and easy handling in manufacturing.

The TPSM560R6 is a compact, easy-to-use power module with a wide adjustable output voltage range of 1.0 V to 6 V. The total solution requires as few as four external components and eliminates the loop compensation and magnetics part selection from the design process. The full feature set includes power good, programmable UVLO, prebias start-up, overcurrent, and temperature protections, making the TPSM560R6 an excellent device for powering a wide range of applications. Space-constrained applications benefit from the 5.0-mm × 5.5-mm package.
