PMIC DC Power Management 590khz TPS562207SDRLR Overcurrent Protection

Features for the TPS562207S

• 2-A converter with integrated 140-mΩ and 84-mΩ FETs
• D-CAP2™ mode control with fast transient response
• Input voltage range: 4.3 V to 17 V
• Output voltage range: 0.804 V to 7 V
• Forced continuous conduction mode
• 580-kHz switching frequency
• Low shutdown current of less than 3 µA
• 1.5% feedback voltage accuracy (25°C)
• Supports pre-bias start-up
• Cycle-by-cycle overcurrent limit
• Hiccup-mode overcurrent protection
• Non-latch UVP and TSD protections
• Fixed soft start: 1.2 ms

Description for the TPS562207S

The TPS562207S is a simple, easy-to-use, 2-A synchronous buck converter in a SOT563 package.

The device is optimized to operate with minimum external components and also optimized to achieve low standby current.

This switch mode power supply (SMPS) device employs D-CAP2 mode control providing a fast transient response and supporting both low-equivalent series resistance (ESR) output capacitors such as specialty polymer and ultra-low ESR ceramic capacitors with no external compensation components.

The TPS562207S operates in Forced Continuous Conduction Mode (FCCM), which maintains fixed switching frequency and output voltage ripple is very small. The TPS562207S is available in a 6-pin 1.6-mm × 1.6-mm SOT563 (DRL) package, and specified from a –40°C to 125°C junction temperature.
