POWER LED DRIVER IC TLE6284G - TECHNOLOGIES AG - H-BRIDGE DRIVER IC NEW AND ORIGINA
| High Light: |
power led driver circuit,offline led driver ic |
||
|---|---|---|---|
Quick Detail:
H-Bridge Driver IC
Description:
H-bridge driver IC for MOSFET power stages with multiple protection functions.
The TLE6184G is very similar to the TLE6281G. The major difference is that the Short Circuit protection level of the TLE6284G can be adjusted by external resistors or even disabled. The pin outs are different as well.
Applications:
• Compatible to very low ohmic normal level input N-Channel MOSFETs
• PWM – DIR - Interface
• PWM frequency up to 50kHz
• Operates down to 7.5 V supply voltage
• Low EMC sensitivity and emission
• Adjustable dead time with shoot through protection
• Deactivation of dead time and shoot through protection possible
• Short circuit protection for each Mosfet can be disabled and adjusted
• Driver undervoltage shut down
• Reverse polarity protection for the driver IC
• Fast disable function / Inhibit for low quiescent current
• Input with TTL characteristics
• 2 bit diagnosis
• Thermal overload warning for driver IC
• Shoot through protection
• Integrated bootstrap diodes
Specifications:
| Datasheets | TLE6284G |
| Product Photos | 20-SOIC 0.295 |
| Standard Package | 1 |
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Motor and Fan Controllers, Drivers |
| Series | - |
| Packaging | Cut Tape (CT) |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Pre-Driver |
| Interface | Parallel |
| Applications | General Purpose |
| Current - Output | - |
| Voltage - Supply | 7.5 V ~ 60 V |
| Voltage - Load | - |
| Operating Temperature | -40°C ~ 150°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | PG-DSO-20 |
| Other Names | TLE6284GCT |
