MCU Microcontroller Unit S87C752-1DB- -80C51 8-bit microcontroller family 2K/64 OTP/ROM, 5 channel 8 bit A/D,
| High Light: |
micro controller unit,microcontroller modules |
||
|---|---|---|---|
Quick Detail:
80C51 8-bit microcontroller family 2K/64 OTP/ROM, 5 channel 8 bit A/D, I2C, PWM, low pin count
Description:
The 83C752/87C752 offers many of the advantages of the 80C51 architecture in a small package and at low cost.
The 8XC752 Microcontroller is fabricated with high-density CMOS technology. epitaxial substrate minimizes CMOS latch-up sensitivity.
The 8XC752 contains a 2k × 8 ROM (83C752) EPROM (87C752), a
64 × 8 RAM, 21 I/O lines, a 16-bit auto-reload counter/timer, a fixed-priority level interrupt structure, a bidirectional inter-integrated circuit (I2C) serial bus interface, an on-chip oscillator, a five channe multiplexed 8-bit A/D converter, and an 8-bit PWM output.
The onboard inter-integrated circuit (I2C) bus interface allows the
8XC752 to operate as a master or slave device on the I2C small area network. This capability facilitates I/O and RAM expansion, access to EEPROM, processor-to-processor communication, and efficient interface to a wide variety of dedicated I2C peripherals.
The EPROM version of this device, the 87C752, is available in both quartz-lid erasable and plastic one-time programmable (OTP) packages. Once the array has been programmed, it is functionally equivalent to the masked ROM 83C752. Thus, unless explicitly stated otherwise, all references made to the 83C752 apply equally to the 87C752.
The 83C752 supports two power reduction modes of operation referred to as the idle mode and the power-down mode.
Applications:
• Available in erasable quartz lid or One-Time Programmable plastic packages
• 80C51 based architecture
• Inter-integrated Circuit (I2C) serial bus interface
• Small package sizes
– 28-pin DIP
– 28-pin PLCC
– 28-pin SSOP
• Wide oscillator frequency range
• Low power consumption:
– Normal operation: less than 11mA @ 5 V, 12 MHz
– Idle mode
– Power-down mode
• 2k × 8 ROM (83C752) EPROM (87C752)
• 64 × 8 RAM
• 16-bit auto reloadable counter/timer
• 5-channel 8-bit A/D converter
• 8-bit PWM output/timer
• Fixed-rate timer
• Boolean processor
• CMOS and TTL compatible
• Well suited for logic replacement, consumer and industrial applications
Specifications:
| part no. | S87C752-1DB |
| Manufacturer | |
| supply ability | 10000 |
| datecode | 10+ |
