Modules MCU Microcontroller Unit 16 Bit SAB80C166-S CMOS Microcontroller

Minimum Order Quantity: 10 PCS
Modules MCU Microcontroller Unit 16 Bit SAB80C166-S CMOS Microcontroller
Features Gallery Product Description Request A Quote
Manufacturer Part Number: SAB80C166-S
Brand Name: Original
D/C: Newst
Packaging: Original Packaging
Port: Shenzhen Or Hongkong
Lead Time: 1-3Working Days
High Light:

Modules MCU Microcontroller Unit


MCU Microcontroller Unit 16 Bit



Basic Infomation
Place of Origin: Original Factory
Brand Name: SIEMENS
Certification: ROHS COMPLIANT
Model Number: SAB80C166-S
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 1000
Product Description



High Light:

micro controller unit


microcontroller modules




Quick Detail:


High-Performance CMOS 16-Bit Microcontroller





The C167CR derivatives are high performance derivatives of the C166 Family of full featured single-chip CMOS microcontrollers. They combine high CPU performance (up to 16.5 million instructions per second) with high peripheral functionality and enhanced IO-capabilities. They also provide clock generation via PLL and various on-chip memory modules such as program ROM, internal RAM, and extension RAM.




• High Performance 16-bit CPU with 4-Stage Pipeline

– 80/60 ns Instruction Cycle Time at 25/33 MHz CPU Clock

– 400/303 ns Multiplication (16 × 16 bits), 800/606 ns Division (32 / 16 bits)

– Enhanced Boolean Bit Manipulation Facilities

– Additional Instructions to Support HLL and Operating Systems

– Register-Based Design with Multiple Variable Register Banks

– Single-Cycle Context Switching Support

– 1024 Bytes On-Chip Special Function Register Area

• 16-Priority-Level Interrupt System with 56 Sources, Sample-Rate down to 40/30 ns

• 8-Channel Interrupt-Driven Single-Cycle Data Transfer Facilities via

Peripheral Event Controller (PEC)

• Clock Generation via on-chip PLL (factors 1:1.5/2/2.5/3/4/5), via prescaler or via direct clock input

• On-Chip Memory Modules

– 2 Kbytes On-Chip Internal RAM (IRAM)

– 2 Kbytes On-Chip Extension RAM (XRAM)

– 128/32 Kbytes On-Chip Mask ROM

• On-Chip Peripheral Modules

– 16-Channel 10-bit A/D Converter with Programmable Conversion Time down to 7.8 µs

– Two 16-Channel Capture/Compare Units

– 4-Channel PWM Unit

– Two Multi-Functional General Purpose Timer Units with 5 Timers

– Two Serial Channels (Synchronous/Asynchronous and High-Speed-Synchronous)

– On-Chip CAN Interface (Rev. 2.0B active) with 15 Message Objects

(Full CAN / Basic CAN)

• Up to 16 Mbytes External Address Space for Code and Data

– Programmable External Bus Characteristics for Different Address Ranges

– Multiplexed or Demultiplexed External Address/Data Buses with 8-Bit or 16-Bit Data Bus Width

– Five Programmable Chip-Select Signals

– Hold- and Hold-Acknowledge Bus Arbitration Support

• Idle and Power Down Modes

• Programmable Watchdog Timer and Oscillator Watchdog

• Up to 111 General Purpose I/O Lines, partly with Selectable Input Thresholds and Hysteresis

• Supported by a Large Range of Development Tools like C-Compilers,

Macro-Assembler Packages, Emulators, Evaluation Boards, HLL-Debuggers, Simulators, Logic Analyzer Disassemblers, Programming Boards

• On-Chip Bootstrap Loader

• 144-Pin MQFP Package

• 176-Pin BGA Package1





part no. SAB80C166-S
Manufacturer SIEMENS
supply ability 10000
datecode 10+
package QFP100
remark new and original stock
