Programmable IC Chip C5VLX85T-2FF1136I Virtex-5 FPGA circuit

Minimum Order Quantity: 1
MOQ
negotiate
Price
Programmable IC Chip C5VLX85T-2FF1136I Virtex-5 FPGA circuit
Features Gallery Product Description Request A Quote
Features
Specifications
Features: Standard
Model Number: C5VLX85T-2FF1136I
Brand Name: Original
Place Of Origin: Philippines
Packaging Type: Standard
Type: Integrated Circuit
Basic Infomation
Place of Origin: Original Factory
Brand Name: xilinx
Certification: Lead free / RoHS Compliant
Model Number: C5VLX85T-2FF1136I
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 2000
Product Description

PROGRAMMABLE IC CHIP XC5VLX85T-2FF1136I - XILINX - VIRTEX-5 FPGA



Detailed Product Description
High Light:

ic integrated circuits

,

integrated circuit chips







Quick Detail:



Virtex-5 FPGA





Description:



Virtex®-5 FPGAs are available in -3, -2, -1 speed grades, with -3 having the highest performance. Virtex-5 FPGA DC and AC characteristics are specified for both commercial and industrial grades. Except the operating temperature range or unless otherwise noted, all the DC and AC electrical parameters are the same for a particular speed grade (that is, the timing characteristics of a -1 speed grade industrial device are the same as for a -1 speed grade commercial device). However, only selected speed grades and/or devices might be available in the industrial range.

All supply voltage and junction temperature specifications are representative of worst-case conditions. The parameters included are common to popular designs and typical applications.





Applications:



• Virtex-5 Family Overview

• Virtex-5 FPGA User Guide

• Virtex-5 FPGA Configuration Guide

• Virtex-5 FPGA XtremeDSP™ Design Considerations

• Virtex-5 FPGA Packaging and Pinout Specification

• Embedded Processor Block in Virtex-5 FPGAs Reference Guide

• Virtex-5 FPGA RocketIO™ GTP Transceiver User Guide

• Virtex-5 FPGA RocketIO GTX Transceiver User Guide

• Virtex-5 FPGA Embedded Tri-Mode Ethernet MAC User Guide

• Virtex-5 FPGA Integrated Endpoint Block User Guide for PCI Express® Designs

• Virtex-5 FPGA System Monitor User Guide

• Virtex-5 FPGA PCB Designer’s Guide





Specifications:



Datasheets Virtex-5 FPGA Datasheet
Virtex-5 Family Overview
Virtex-5 FPGA User Guide
Product Photos Xilinx- 1136-FBGA
PCN Packaging Virtex-5, SXT FPGA 11/March/2008
Standard Package 1
Category Integrated Circuits (ICs)
Family Embedded - FPGAs (Field Programmable Gate Array)
Series Virtex®-5 LXT
Number of LABs/CLBs 6480
Number of Logic Elements/Cells 82944
Total RAM Bits 3981312
Number of I /O 480
Number of Gates -
Voltage - Supply 0.95 V ~ 1.05 V
Mounting Type Surface Mount
Operating Temperature -40°C ~ 100°C
Package / Case 1136-BBGA, FCBGA
Supplier Device Package 1136-FCBGA (35x35)
For Use With 568-5088-ND - BOARD DEMO DAC1408D750
122-1586-ND - BOARD EVAL FOR VIRTEX-5 ML555
HW-AFX-FF1136-500-G-ND - BOARD DEV VIRTEX 5 FF1136
