PCI Programmable IC Chip Original XCR3128-12VQ100I Macrocell CPLD

Minimum Order Quantity: 10 PCS
PCI Programmable IC Chip Original XCR3128-12VQ100I Macrocell CPLD
Features Gallery Product Description Request A Quote
Manufacturer Part Number: XCR3128-12VQ100I
Brand Name: Original Brand
Type: Integrated Circuit
Place Of Origin: Original Manufacturer
Description: New In Original
Shipping: Within 3days
High Light:

PCI Programmable IC Chip


Programmable IC Chip Original


Macrocell CPLD

Basic Infomation
Place of Origin: Original Factory
Brand Name: xilinx
Certification: Lead free / RoHS Compliant
Model Number: XCR3128-12VQ100I
Payment & Shipping Terms
Packaging Details: Standard Packaging
Delivery Time: Within 3days
Payment Terms: T/T in advance, Western Union, Xtransfer
Supply Ability: 1000
Product Description



High Light:

ic integrated circuits


integrated circuit chips



Quick Detail:
XCR3128: 128 Macrocell CPLD
The XCR3128 CPLD (Complex Programmable Logic Device) is the third in a family of CoolRunner® CPLDs from Xilinx. These devices combine high speed and zero power in a 128 macrocell CPLD. With the FZP design technique, the XCR3128 offers true pin-to-pin speeds of 10 ns, while simultaneously delivering power that is less than 100 µA at standby without the need for ‘turbo-bits’ or other power-down schemes. By replacing conventional sense amplifier methods for implementing product terms (a technique that has been used in PLDs since the bipolar era) with a cascaded chain of pure CMOS gates, the dynamic power is also substantially lower than any competing CPLD. These devices are the first TotalCMOS PLDs, as they use both a CMOS process technology and the patented full CMOS FZP design technique. For 5V applications, Xilinx also offers the high speed XCR5128 CPLD that offers these features in a full 5V implementation.
The Xilinx FZP CPLDs utilize the patented XPLA (eXtended Programmable Logic Array) architecture. The XPLA architecture combines the best features of both PLA and PAL type structures to deliver high speed and flexible logic allocation that results in superior ability to make design changes with fixed pinouts. The XPLA structure in each logic block provides a fast 10 ns PAL path with five dedicated product terms per output. This PAL path is joined by an additional PLA structure that deploys a pool of 32 product terms to a fully programmable OR array that can allocate the PLA product terms to any output in the logic block. This combination allows logic to be allocated efficiently throughout the logic block and supports as many as 37 product terms on an output. The speed with which logic is allocated from the PLA array to an output is only 2.5 ns, regardless of the number of PLA product terms used, which results in worst case tPD’s of only 12.5 ns from any pin to any other pin. In addition, logic that is common to multiple outputs can be placed on a single PLA product term and shared across multiple outputs via the OR array, effectively increasing design density.
The XCR3128 CPLDs are supported by industry standard CAE tools (CadencE/OrCAD, Exemplar Logic, Mentor, Synopsys, Synario, Viewlogic, and Synplicity), using text (ABEL, VHDL, Verilog) and/or schematic entry. Design verification uses industry standard simulators for functional and timing simulation. Development is supported on personal computer, Sparc, and HP platforms. Device fitting uses a Xilinx developed tool, XPLA Professional (available on the Xilinx web site).
• Industry's first TotalCMOS™ PLD - both CMOS design and process technologies
• Fast Zero Power (FZP™) design technique provides ultra-low power and very high speed
• IEEE 1149.1-compliant, JTAG Testing Capability
- Four pin JTAG interface (TCK, TMS, TDI, TDO)
- IEEE 1149.1 TAP Controller
- JTAG commands include: Bypass, Sample/Preload, Extest, Usercode, Idcode, HighZ
• 3.3V, In-System Programmable (ISP) using the JTAG interface
- On-chip supervoltage generation
- ISP commands include: Enable, Erase, Program,
- Supported by multiple ISP programming platforms
• High speed pin-to-pin delays of 10 ns
• Ultra-low static power of less than 100 µA
• 100% routable with 100% utilization while all pins and all macrocells are fixed
• Deterministic timing model that is extremely simple to use
• Four clocks available
• Programmable clock polarity at every macrocell
• Support for asynchronous clocking
• Innovative XPLA™ architecture combines high-speed with extreme flexibility
• 1000 erase/program cycles guaranteed
• 20 years data retention guaranteed
• Logic expandable to 37 product terms
• PCI compliant
• Advanced 0.5µ E2CMOS process
• Security bit prevents unauthorized access
• Design entry and verification using industry standard and Xilinx CAE tools
• Reprogrammable using industry standard device programmers
• Innovative control term structure provides either sum terms or product terms in each logic block for:
- Programmable 3-state buffer
- Asynchronous macrocell register preset/reset
- Programmable global 3-state pin facilitates "bed of nails" testing without using logic resources
- Available in PLCC, VQFP, and PQFP packages
- Available in both commercial and industrial grades

part no. XCR3128-12VQ100I
Manufacturer xilinx
supply ability 10000
datecode 10+
package TQFP
remark new and original stock
