MC100LVEL29DWR ---- 3.3V ECL DUAL DIFFERENTIAL DATA AND CLOCK D FLIP?FLOP WITH SET AND RESET
| High Light: |
computer integrated circuits,computer ic chip |
||
|---|---|---|---|
Quick Detail:
3.3V ECL Dual Differential Data and Clock D Flip?Flop With Set and Reset
Specifications:
| Datasheets | MC100LVEL29 Series |
| Product Photos | 20-SOIC |
| Standard Package | 38 |
| Category | Integrated Circuits (ICs) |
| Family | Logic - Flip Flops |
| Series | 100LVEL |
| Packaging | Tube |
| Function | Set(Preset) and Reset |
| Type | D-Type |
| Output Type | Differential |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Frequency - Clock | 1.1GHz |
| Delay Time - Propagation | 580ps |
| Trigger Type | Positive Edge |
| Current - Output High, Low | - |
| Voltage - Supply | 3 V ~ 3.8 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Dynamic Catalog | 100LVEL |
| Other Names | MC100LVEL29DWGOS |
