Name: 600v 16a Mosfet Power Transistor TO-247-3 IRFPC60PBF Through Hole
Brand: IR
SKU: IRFPC60PBF
Rating: 4.6 (152 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Manufacturer Part Number: IRFPC60PBF

Brand Name: Original

Type: Integrated Circuit

Place Of Origin: Original Manufacturer

DC: Lastest New

Lead Time: 1-3Working Days

High Light:

600v Mosfet Power Transistor

16a Mosfet Power Transistor

IRFPC60PBF

Basic Infomation

Place of Origin: Original Factory

Brand Name: IR

Certification: Standard Certification

Model Number: IRFPC60PBF

Payment & Shipping Terms

Packaging Details: Standard Packaging

Delivery Time: Within 3days

Payment Terms: T/T in advance, Western Union, Xtransfer

Supply Ability: 1000

Gallery

600v 16a Mosfet Power Transistor TO-247-3 IRFPC60PBF Through Hole

Product Description

IRFPC60PBF MOSFET POWER TRANSISTOR 600V 16A THROUGH HOLE TO-247-3

Goods Condition:	Brand New	Part Status:	Active
Lead Free / Rohs:	Complaint	Function:	MOSFET
Mounting Type:	Through Hole	Package:	TO247
High Light:	high power mosfet transistors , n channel transistor

IRFPC60PBF MOSFET TRANSISTOR N-Channel 600V 16A (Tc) 280W (Tc) Through Hole TO-247-3

FEATURES
• Dynamic dV/dt Rating
• Repetitive Avalanche Rated
• Isolated Central Mounting Hole
• Fast Switching
• Ease of Paralleling
• Simple Drive Requirements
• Lead (Pb)-free Available

DESCRIPTION
Third generation Power MOSFETs from Vishay provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-247 package is preferred for commercial-industrial applications where higher power levels preclude the use of TO-220 devices. The TO-247 is similar but superior to the earlier TO-218 package because of its isolated mounting hole. It also provides greater creepage distance between pins to meet the requirements of most safety specifications.

Manufacturer	Vishay Siliconix
Series	-
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	600V
Current - Continuous Drain (Id) @ 25°C	16A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Vgs(th) (Max) @ Id	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	210nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	3900pF @ 25V
FET Feature	-
Power Dissipation (Max)	280W (Tc)
Rds On (Max) @ Id, Vgs	400 mOhm @ 9.6A, 10V
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-247-3
Package / Case	TO-247-3
