AD7799BRUZ-REEL -3-CHANNEL, LOW NOISE, LOW POWER, 16-/24-BIT, Σ-Δ ADC WITH ON-CHIP IN-AMP
Quick Detail:
3-Channel, Low Noise, Low Power, 16-/24-Bit, Σ-Δ ADC with On-Chip In-Amp
Specifications:
| Datasheets | AD7798-99 |
| Product Photos | 16-TSSOP |
| Standard Package | 2,500 |
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Number of Bits | 24 |
| Sampling Rate (Per Second) | 470 |
| Data Interface | DSP, MICROWIRE™, QSPI™, Serial, SPI™ |
| Number of Converters | 1 |
| Power Dissipation (Max) | 2.5mW |
| Voltage Supply Source | Analog and Digital |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| Number of Inputs and Type | 3 Differential, Unipolar; 3 Differential, Bipolar |
| Dynamic Catalog | 24 Bit |
| For Use With | EVAL-AD7799EBZ-ND - BOARD EVALUATION FOR AD7799 |
| Other Names | AD7799BRUZ-REEL-ND AD7799BRUZ-REELTR |
